กระดานอิเล็กทรอนิกส์ Plus C20W
เคลื่อนย้ายง่าย
ฟังก์ชั่นการจับภาพของกระดานอิเล็กทรอนิกส์
รองรับการแปะแผ่นแม่เหล็ก
ระบบสแกนที่รวดเร็ว
รองรับการเชื่อมต่อ USB CABLE
ประชุมอย่างมีประสิทธิผลกับ copyboard Plus C20W
ไวท์บอร์ดอิเล็กทรอนิกส์
ทุกวันมีการประชุมนับไม่ถ้วน สิ่งสำคัญคือต้องมีการประชุมที่มีประสิทธิผลเพื่อให้ได้ผลลัพธ์ที่ดี
และดำเนินธุรกิจ อย่างไรก็ตาม ในหลายกรณี ผู้คนต้องเผชิญกับ "การพบปะที่ไม่รู้จบ"
"การสนทนาที่ไม่พอใจ" "การตัดสินใจที่ไม่เต็มใจ" "การโต้เถียงที่ไร้จุดหมาย" เป็นต้น คุณจะทำให้การประชุมของเราทำงานได้อย่างไร
วาดภาพความคิดของคุณด้วยการวาดข้อความและภาพวาดบนกระดาน
ช่วยให้ผู้คนจดจำประเด็นของคุณได้อย่างง่ายดายและมีส่วนร่วมในกระบวนการโดยการเพิ่มความคิดเห็นของตนเองบนกระดาน
การใช้มาร์กเกอร์สีต่างๆ จะช่วยให้คุณจัดระเบียบเนื้อหาบนกระดานได้ชัดเจนยิ่งขึ้นสำหรับสมาชิก
เมื่อการประชุมสิ้นสุดลง เพียงแค่กดปุ่มบนกระดาน สมาชิกแต่ละคนสามารถแบ่งปันข้อมูลเดียวกันกับฉันทามติได้
ผลลัพธ์ :
– ข้อมูลภาพบนกระดานได้รับการยอมรับว่าเป็นเป้าหมายร่วมกันโดยสมาชิกซึ่งจะช่วยส่งเสริมการมีส่วนร่วมได้ดีขึ้นมาก
– การประชุมมีชีวิตชีวามากขึ้นและช่วยให้ผู้คนดำเนินการอย่างมีเหตุผลและชัดเจน
– การขจัดความตึงเครียดที่ไม่จำเป็นและการป้องกันการโต้เถียงทำให้เกิดการอภิปรายที่สร้างสรรค์
- สามารถตัดสินใจได้อย่างมั่นคง
– การแบ่งปันข้อมูลในสถานที่ทำให้ง่ายต่อการดำเนินการอย่างถูกต้องทันทีหลังการประชุม ธุรกิจ
ทำงานได้อย่างราบรื่น Plus C20W
series name | Plus C20W | C-20S | |||
---|---|---|---|---|---|
Panel size |
Wide |
Standard | |||
Number of panels |
2 |
2 | |||
Outer Dimensions with stand (Max)*1 |
W1980 ?~ D675 ?~ H1947mm |
W1480 ?~ D675 ?~ H1947 mm W58.3 ?~ D26.6 ?~ H76.7 inches |
|||
Weight with stand (excluding printer) |
38.5kg / 84.8 lbs. |
33.5kg / 73.9 lbs. | |||
Board | Panel size |
W1800 ?~ H910 mm |
W1300 ?~ H910 mm W51.2 ?~ H35.8 inches |
||
Effective reading size | W1780 ?~ H900 mm W70.1 ?~ H35.4 inches |
W1280 ?~ H900 mm W50.4 ?~ H35.4 inches |
|||
Number of panels | 2 | ||||
Grid | – | ||||
Paging | Endless in one direction(horizontal scrolling) | ||||
Sheet driving method | Motorized / Manual | ||||
Reading method | CIS (Contact Image Sensor) | ||||
Reading illumination light source | RGB LED | ||||
Reading resolution | Main scanning direction (vertical sheet surface) 1.92 dots / mm (50 dpi or equivalent), Sub scanning direction (horizontal sheet surface) 1.92 dots / mm (50 dpi or equivalent) |
||||
Reading time |
Color: approx. 21 sec |
Color: approx. 15 sec3 Black & White: approx. 15 sec |
|||
Printer*2 | |||||
Compatible inkjet printers | Epson single/multi function printers HP PCL3e and some PCL3GUI printers |
||||
Printing size | A4 / Letter-size | ||||
Printing paper size | A4 (210 x 297 mm) / Letter-size (8.5 x 11″) | ||||
Colors | Color or Black & White | ||||
Continuous printing | 1 to 10 copies | ||||
Interface | USB2.0 Hi-Speed | ||||
Interface | Board | File format | JPEG / PNG / PDF | ||
Screen size |
Standard resolution: 1728 x 864 dots |
Standard resolution: 1248 x 864 dots High resolution: 2496 x 1728 dots |
|||
External memory*3 | Type | USB flash memory | |||
Compatible FAT types | FAT16, 32 | ||||
Interface | USB 2.0 Hi-Speed | ||||
Network | LAN port | RJ-45 (10Base-T/100Base-TX) |
|||
Printing | Printing | resolution 300 dpi or equivalent | |||
No. print colors | 16 or grayscale | ||||
Printer interface | USB 2.0 Hi-Speed | ||||
Power supply | AC power adapter | Input: AC 100-240V/50-60 Hz, Max 0.75A Output: DC 12V, 3.0A |
|||
Power consumption | Standby : 3W, Operation : 12W | ||||
Operating conditions | Temperature | 10-35?‹C, 50-95 ?‹F | |||
Humidity | 30 – 85%?@(no condensation) | ||||
Accessories |
Dedicated markers (black, red, blue, green), |
||||
Computer operating environment*6 | Operating system | When using C-20 software: Microsoft Windows XP (Home Edition / Professional Edition Service Pack 3 or later) / Windows Vista (32bit) / Windows 7 (32bit / 64bit)When use the Copyboard as a removable disk: Microsoft Windows XP (Home Edition / Professional Edition Service Pack 2 or later) / Windows Vista (32bit / 64bit) / Windows 7 (32bit / 64bit)Or, Apple Macintosh computer with standard USB port, Mac OS X 10.5 or later | |||
Web browser | Internet Explorer 8.0 or later Safari 5 or later *Enable JavaScript |
||||
Compatible computer types | Preinstalled models operating on one of the operating systems above |
