เครื่องขยายเสียง ITC TS-350PI ราคาพิเศษ
Features เครื่องขยายเสียง ITC TS-350PI
• Industrial modeling steel panel, professional design with durable surface,
- the panel can be folded wash by the air filter design, removable cleaning cooling vents.
• Start soft start to prevent power to the grid absorb a large current, interference with other electrical equipment.
• Intelligent control forced cooling designs, low fan noise, and high thermal efficiency.
• Two-channel amplifier input sensitivity can select third gear, easy to accept wide input amplitude range of the signal source.
• Complete and reliable security protection measures and working status indicator
- (short circuit, overload, DC and overheating protection, transformer overheating protection),
- allow users to be assured use.
• Intelligent clipping limiter controls the power module and the speaker system works in a safe range.
• Standard XLR + TRS1 / 4 “composite input interface, simple interface is more convenient to meet different user needs.
• High-quality large-capacity transformer and a low resistance electrolytic filter, ensure a large dynamic operating handle it.
• Adapting to different situations, choose the optional stereo or bridged mode.
• The input pin to ground and suspension seat ground control.
เครื่องขยายเสียง ITC TS-350PI
Specifications
Output Power (20-20KHz/THD≤1%) | TS-200PI | TS-350PI |
Stereo / Parallel 8Ω X 2 | 200W x 2 | 350W x 2 |
Stereo / Parallel 4Ω X 2 | 300W x 2 | 530W x 2 |
Bridge 8Ω | 600W | 1060W |
Connecting Plug | XLR, TRS interface | |
Voltage Gain (@1KHz) | 32dB | 34.4dB |
Input Sensitivity | 0.775V/1V/1.44V | |
Input Impedance | 10KΩunbalanced, 20KΩbalanced | |
Frequency Response (@ 1W Power ) | 20-20KHz/±1dB | |
THD+N | ≤0.05% | |
S/N Ratio (A-weighted) | ≥90dB | |
Damping Coefficient (@ 1KHz) | ≥200@ 8Ω | |
Resolution (@1KHz) | ≥80dB | |
Protection Mode | Overcurrent protection, DC protection, short circuit protection | |
Indicator Light | Power, protection, distortion | |
Cooling Mode | Fan cooling | |
Power Supply | ~ 220-240V 50/60Hz | |
Maximum Power Consumption | 900W | 1600W |
Dimensions (L x W x H) | 483 x 394 x 88mm | |
Weight | 11.2Kg | 12.6Kg |
ไฟล์เออกสาร PDF : ITC TS-350PI
