Kystar KLS12

Kystar KLS12 Two in one controller

Summary

KSV12 two-in-one controller supports 4K@30Hz digital signal input and has 12 network port outputs. The whole machine can carry a maximum load of 7.8 million pixels. It adopts a pure hardware FPGA architecture and can run continuously for 365×24 hours to meet the needs of small spacing. Application configuration requirements for large screen control systems.

Features

• The single machine has 12 network ports. A single network port can carry 650,000 pixels. The whole machine can carry a maximum of 7.8 million pixels. The width can reach 12,000 points and the height can reach 4,000 points.
• Supports a variety of digital signal interfaces, including 1 DP1.1, 1 HDMI1.4, 2 HDMI1.3 and 2 DVI-D input sources.
• Supports 3-picture display, with arbitrary layout of picture positions.
• All layers support cutout and transparency adjustment to present the best effect.
• Supports a variety of special effects when switching between different signals, including fade in and out, up, down, left and right swiping, diagonal up and down swiping, circular cut-in and cut-in, diamond-shaped cut-in and cut-in, and comb-shaped switching.
• Support signal source hot backup.
• EDID configuration management: supports reading, modifying, and customizing EDID (Extended Display Identification Data).
• Supports one-click black screen/freeze function.
• Black border removal/cropping function: Solve the black border problem caused by front-end signals, and perform arbitrary cropping for any signal source (still maintain full screen status)
• Supports key lock to prevent misoperation.
• The overall output screen display brightness and contrast can be adjusted in real time and quickly.
• K-HDR function supports SDR to HDR image optimization technology, which can improve the contrast of ordinary SDR videos, enhance image details, and make ordinary videos have HDR effects.

Front panel Kystar KLS12

 Back panel Kystar KLS12

ขนาดเครื่อง
