เครื่องขยายเสียง CMX IP-6350

Description เครื่องขยายเสียง CMX IP-6350 :
- The IP Amplifier, which combine the IP network audio decoder/IP streaming and 100V/8 Ohm amplifier together.
- The IP amplifier is of 19” rack mount design, it is built-in amplifier rated output at 350W.
- The IP network technology also allow this IP network amplifier could be installed anywhere
- even near to the speaker to save cable wiring from control room to each zone.
- The advantages of the network audio system are: Super distance audio transmission,
- multiple channel audio matrix, simultaneous multiple programs and non-dedicated network wiring.
Feature เครื่องขยายเสียง CMX IP-6350 :
- IP amplifier with audio decoder.
- Simple system configuration by system server, paging microphone & IP network amplifier to set up IP audio system.
- Huge system capacity of 6,000 zones paging and multiple BGM system.
- IP based public address system over LAN/WAN or Internet.
- Minimum cable connection by using existing network framework.
- Non-dedicated network audio system solution.
- Economy network PA system for multiple room and multiple program applications.
- Ideal for school, office, restaurant and fitness center IP PA sound system.
- IP network decoder built-in 100V/8 Ohm Amplifier.
- Rated power output of 350W.
- Three microphone inputs and two line inputs and one line output.
- Enable to broadcast Mp3 program or pre-recorded voice message from PC server to IP amplifier.
- Remote volume control and program control from server room.
- Timely broadcast ring bell or pre-recorded message to pre-set zones.
- IP remote paging microphone enables to talk to each speaker zone or amplifier over network.
Specification
| Model |
| IP-6350 |
| Description |
| IP Network Amplifier |
| Rated Power Output |
| 350W |
| Protocol Support |
| TCP/IP, UDP, IGMP (group broadcasting) |
| Transmit Speed |
| 10/100Mbps |
| Audio Format |
| 16 digit stereo CD tone |
| Frequency Response |
| 20Hz~16KHz |
| THD |
| ≤0.3% |
| S/N Ratio |
| ≥85dB |
| Connector |
| One RJ45 port, three mic inputs and two line input and one line output |
| Speaker Output |
| 100V/70V & 8 Ohm |
| Working Temp |
| -5℃ to +40℃ |
| Humidity |
| 10% ~ 90% |
| Power Consumption |
| 485W |
| Power Supply |
| AC220V, 50-60Hz |
| Dimensions |
| 484x366x88mm |
| Weight |
| 14.5kg |
